Brandt VSM300 Primary Scalping Secondary Shale shaker screen
Brandt VSM300 Primary Scalping Secondary Shale shaker screen
Brandt VSM300 Primary Scalping Secondary Shale shaker screen
Brandt VSM300 Primary Scalping Secondary Shale shaker screen

Brandt VSM300 Primary Scalping Secondary Shale shaker screen

Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF
Delivery Time: 3 Days

Contact Now Add to Basket

Additional Info

    Packaging: Per sheet by carton box,then Wooden box

    Productivity: 600Pcs/day

    Brand: Shengjia

    Transportation: Ocean,Air

    Place of Origin: Hengshui,Hebei,China

    Supply Ability: 10000pcs

    Certificate: API ,ISO9001-2000

    HS Code: 84219990

    Port: Xingang Port

Product Description



Brandt VSM300 Shale shaker screen

VSM300 have three sizes as below ,

Dimension Weight Non-blanked Area(Sq.ft)

Scalping 940x676x38mm 10.5kgs 4.6

Primary 885x686x38mm 10kgs 4.3


Secondary 686x208x20mm 3kgs 2.3



Plastic types:


VSM300 Series shaker screen is used to replace screen on VSM300 Shale shaker.

VSM300 is from NOV Brandt. It has special design on shaker decks. There are totally 3 decks. Each deck requests different shaker screens. Such as primary deck, first deck and the secondary deck screen. However, all of them are pretensioned screen

P3090321

P3090322


Shale Shaker Screen (1)


Shale Shaker Screen (1)




these Steel frame screens are mostly applied to the shale shakers with wedge fastening equipment. The screen frames adopt that high-strength square steel tube welded to multi-ribbed construction. They are sturdy and reliable. These screens are constructed with two or three stainless steel layers bonded to a steel support plank. Accessary rubber plugs may be used to repair rips or tears. By doing this, we can cut down time and reduce the production costs. We can supply steel frame screens with mesh sizes ranging from 20 to 250.


Plastic types:


P1060428


P1060431


P1060518



Package: inside carton and outside wooden cases


Shale Shaker Screen (10)







Looking for ideal Brandt VSM300 Primary Scalping Secondary Shale Shaker Screen Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Brandt VSM300primary are quality guaranteed. We are China Origin Factory of VSM 300 Shale Shaker. If you have any question, please feel free to contact us.

Product Categories : Oil Shale Shaker Screen Series > Composite Frame Shaker Screen
